Alienware 15 R3 - AR3-1764
Alienware 15 R3
Product code: AR3-1764
- đģDisplay diagonal: 15.6 inch
- đŗProcessor model: i7-7700HQ
- đĢInternal memory: 16 GB
- đŽOn-board graphics adapter model: Intel HD Graphics 630
- đŽDiscrete graphics adapter model: NVIDIA GeForce GTX 1060
- đŊTotal storage capacity: 1256 GB
- âī¸Weight: 3.49 kg
đ Add to compare
Specifications
| Design | |
|---|---|
| Product colour | Silver |
| Product type | Notebook |
| Form factor | Clamshell |
| Market positioning | Gaming |
| Display | |
| Display diagonal | 15.6 inch |
| Pixel pitch | 0.17925 x 0.17925 mm |
| Display brightness | 400 cd/mò |
| Panel type | WVA |
| Display surface | Matt |
| Aspect ratio | 16:9 |
| HD type | Full HD |
| LED backlight | Y |
| Touchscreen | N |
| Display resolution | 1920 x 1080 pixels |
| Brand | Alienware |
| Model name | 15 R3 |
| Part Number | AR3-1764 |
| Release Date | 26 February 2018 |
| EAN/UPC code | 5397184051764 |
|
|
|
| Processor | |
| Processor series | Intel Core i7-7700 Mobile Series |
| Processor family | 7th gen Intel Core i7 |
| Processor frequency | 2.8 GHz |
| Processor boost frequency | 3.8 GHz |
| Processor codename | Kaby Lake |
| Thermal Design Power (TDP) | 45 W |
| Processor model | i7-7700HQ |
| Processor cores | 4 |
| Processor threads | 8 |
| Processor cache | 6 MB |
| Processor lithography | 14 nm |
| Processor socket | BGA 1440 |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 16 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 2400 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 32 GB |
| Memory layout (slots x size) | 2 x 8 GB |
| Maximum internal memory (64-bit) | 32 GB |
| Memory upgrade note | Additional memory sold separately |
| Graphics | |
| On-board graphics adapter | Y |
| Number of discrete graphics adapters installed | 1 |
| NVIDIA G-SYNC | Y |
| Discrete graphics memory type | GDDR5 |
| On-board graphics adapter DirectX version | 12.0 |
| Discrete graphics adapter | Y |
| On-board graphics adapter model | Intel HD Graphics 630 |
| Discrete graphics adapter model | NVIDIA GeForce GTX 1060 |
| On-board graphics adapter base frequency | 350 MHz |
| On-board graphics adapter dynamic frequency (max) | 1100 MHz |
| Maximum on-board graphics adapter memory | 64 GB |
| On-board graphics adapter OpenGL version | 4.4 |
| Discrete graphics adapter memory | 6 GB |
| Storage | |
| Total storage capacity | 1256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| Number of HDDs installed | 1 |
| HDD capacity | 1000 GB |
| HDD speed | 7200 RPM |
| HDD size | 2.5" |
| SSD interface | PCI Express |
| HDD interface | SATA III |
| SSD form factor | M.2 |
| Card reader integrated | N |
| Storage media | HDD+SSD |
| Optical drive | |
| Optical drive type | N |
| Networking | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Wi-Fi | Y |
| WLAN controller model | Killer Wireless-AC 1435 |
| Wi-Fi standards | IEEE 802.11ac |
| Antenna type | 2x2 |
| Bluetooth | Y |
| Bluetooth version | 4.1 |
| 4G | N |
| 3G | N |
| Ports & interfaces | |
| PowerShare | Y |
| Number of USB ports with PowerShare support | 1 |
| Charging port type | DC-in jack |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
| Microphone in | Y |
| HDMI version | 2.0 |
| Alienware graphics amplifier port | Y |
| USB 3.0 (3.1 Gen 1) Type-C ports quantity | 1 |
| Combo headphone/mic port | Y |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Thunderbolt 3 ports quantity | 1 |
| Mini DisplayPorts quantity | 1 |
| Audio | |
| Built-in microphone | Y |
| Number of built-in speakers | 2 |
| Speaker power | 4 W |
| Audio chip | Realtek ALC3266 |
| Camera | |
| Front camera | Y |
| Front camera HD type | HD |
| Front camera resolution | 1280 x 720 pixels |
| Front camera signal format | 720p |
| Front camera resolution (numeric) | 0.92 MP |
| Keyboard | |
| Numeric keypad | N |
| Full-size keyboard | Y |
| Keyboard layout | QWERTZ |
| Keyboard backlit | Y |
| Windows keys | Y |
| Pointing device | Touchpad |
| Keyboard language | German |
| Performance | |
| Virtual Reality (VR) ready | Y |
| Software | |
| Operating system installed | Windows 10 Home |
| Operating system language | German, Dutch, English, French, Italian |
| Operating system architecture | 64-bit |
| Bundled software | Financial Tracker & Retail Information |
| Trial software | McAfee LiveSafe (30 days Trial), Microsoft Office (30 days Trial - Excludes Office License) |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
| Battery capacity (Watt hours) | 68 Wh |
| Weight & dimensions | |
| Weight | 3.49 kg |
| Height | 25.4 mm |
| Depth | 305 mm |
| Width | 389 mm |
| Power | |
| AC adapter power | 180 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| Security | |
| Cable lock slot | Y |
| Cable lock slot type | Noble |
| Password protection | Y |
| Password protection type | BIOS, User |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
