ASUS ExpertBook PM3406CHA-LY0216 - 90NX09U2-M00800
ASUS ExpertBook PM3406CHA-LY0216
Product code: 90NX09U2-M00800
- 💻Display diagonal: 14 inch
- 🔳Processor model: 8840HS
- 🎫Internal memory: 16 GB
- 🎮On-board graphics adapter model:
- 🎮Discrete graphics adapter model:
- 💽Total storage capacity: 512 GB
- ⚖️Weight: 1.54 kg
📊 Add to compare
Specifications
| Design | |
|---|---|
| Product colour | Grey |
| Product type | Laptop |
| Form factor | Clamshell |
| Market positioning | Work |
| Housing material | Plastic |
| Introduction year | 2026 |
| Display back cover material | Aluminium |
| Display | |
| Display diagonal | 14 inch |
| Maximum refresh rate | 60 Hz |
| Contrast ratio (typical) | 800:1 |
| Display brightness | 300 cd/m² |
| HD type | WUXGA |
| LED backlight | Yes |
| Touchscreen | No |
| Display resolution | 1920 x 1200 pixels |
| RGB colour space | NTSC |
| Colour gamut | 45% |
| Native aspect ratio | 16:10 |
| Brand | ASUS |
| Family | ExpertBook |
| Series | P3 G2 |
| Model name | PM3406CHA-LY0216 |
| Part Number | 90NX09U2-M00800 |
| EAN/UPC code | 4711636547987, 0199291547988, 199291547988 |
|
|
|
| Processor | |
| Processor manufacturer | AMD |
| L3 cache | 16 MB |
| Processor family | AMD Ryzen 7 |
| Processor frequency | 3.3 GHz |
| Processor boost frequency | 5.1 GHz |
| Processor model | 8840HS |
| Processor cores | 8 |
| Processor threads | 16 |
| Processor generation | AMD Ryzen 8000 Series |
| Memory | |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 16 GB |
| Memory form factor | SO-DIMM |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 64 GB |
| Memory layout (slots x size) | 1 x 16 GB |
| Graphics | |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | AMD Radeon 780M |
| On-board graphics card family | AMD Radeon Graphics |
| On-board GPU manufacturer | AMD |
| Storage | |
| Total storage capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| Total SSDs capacity | 512 GB |
| SSD interface | PCI Express 4.0 |
| SSD form factor | M.2 |
| Storage media | SSD |
| NVMe | Yes |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.1 |
| Combo headphone/mic port | Yes |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB4 Gen 2x2 ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| Audio | |
| Built-in microphone | Yes |
| Audio system | Dirac |
| Camera | |
| Front camera | Yes |
| Privacy camera | Yes |
| Front camera HD type | Full HD |
| Privacy type | Privacy shutter |
| Front camera resolution | 1920 x 1080 pixels |
| Keyboard | |
| Numeric keypad | No |
| Keyboard layout | QWERTZ |
| Keyboard backlit | Yes |
| Pointing device | Touchpad |
| Keyboard language | Hungarian |
| Copilot key | Yes |
| Software | |
| Operating system installed | No |
| Copilot+ PC | Yes |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
| Battery capacity | 70 Wh |
| Weight & dimensions | |
| Weight | 1.54 kg |
| Height (rear) | 1.89 cm |
| Height (front) | 1.07 cm |
| Depth | 227.8 mm |
| Width | 316 mm |
| Power | |
| AC adapter power | 65 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 20 V |
| AC adapter output current | 3.25 A |
| USB Type-C charging port | Yes |
| USB Type-C required charging power (min) | 55 W |
| USB Type-C required charging power (max) | 65 W |
| Security | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Fingerprint reader | Yes |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Other features | |
| L2 cache | 8 MB |
| Anti-glare screen | Yes |
| Neural processor unit (NPU) | |
| Neural processor unit (NPU) | AMD Ryzen AI |
| Total processor performance up to | 38 TOPs |
| NPU performance up to | 16 TOPs |
