ASUS Vivobook Max X541SA-XO689 - 90NB0CH3-M13610
ASUS Vivobook Max X541SA-XO689
Product code: 90NB0CH3-M13610
- đģDisplay diagonal: 15.6 inch
- đŗProcessor model: N3710
- đĢInternal memory: 4 GB
- đŽOn-board graphics adapter model: Intel HD Graphics 405
- đŽDiscrete graphics adapter model: Not available
- đŊTotal storage capacity: 1 TB
- âī¸Weight: 2 kg
đ Add to compare
Specifications
| Design | |
|---|---|
| Product colour | Black, Chocolate |
| Product type | Laptop |
| Form factor | Clamshell |
| Display | |
| Display diagonal | 15.6 inch |
| HD type | HD |
| LED backlight | Yes |
| Touchscreen | No |
| Display resolution | 1366 x 768 pixels |
| Native aspect ratio | 16:9 |
| Brand | ASUS |
| Family | Vivobook |
| Series | Max |
| Model name | X541SA-XO689 |
| Part Number | 90NB0CH3-M13610 |
| Release Date | 28 April 2020 |
|
|
|
| Processor | |
| Processor series | Intel Pentium N3000 Series for Mobile |
| Processor manufacturer | Intel |
| Processor family | Intel Pentium |
| Processor frequency | 1.6 GHz |
| Processor boost frequency | 2.56 GHz |
| Processor codename | Braswell |
| Thermal Design Power (TDP) | 6 W |
| Processor model | N3710 |
| Processor cores | 4 |
| Processor threads | 4 |
| Processor cache | 2 MB |
| Processor lithography | 14 nm |
| Processor socket | BGA 1170 |
| Memory | |
| Internal memory type | DDR3L-SDRAM |
| Internal memory | 4 GB |
| Memory form factor | On-board |
| Memory clock speed | 1600 MHz |
| Maximum internal memory | 4 GB |
| Graphics | |
| On-board graphics adapter | Y |
| On-board graphics adapter burst frequency | 700 MHz |
| Number of execution units | 16 |
| Discrete graphics adapter | N |
| On-board graphics adapter model | Intel HD Graphics 405 |
| Discrete graphics adapter model | Not available |
| On-board graphics adapter base frequency | 400 MHz |
| Maximum on-board graphics adapter memory | 8 GB |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel HD Graphics 405 |
| On-board graphics card base frequency | 400 MHz |
| Maximum on-board graphics card memory | 8 GB |
| On-board graphics card burst frequency | 700 MHz |
| On-board GPU manufacturer | Intel |
| Storage | |
| Total storage capacity | 1 TB |
| Number of HDDs installed | 1 |
| HDD capacity | 1 TB |
| Total HDDs capacity | 1 TB |
| Compatible memory cards | SD, SDHC, SDXC |
| Card reader integrated | Yes |
| Storage media | HDD |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10, 100 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 4 (802.11n) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Combo headphone/mic port | Yes |
| USB 2.0 ports quantity | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Audio | |
| Built-in microphone | Yes |
| Audio system | SonicMaster |
| Camera | |
| Front camera | Yes |
| Keyboard | |
| Numeric keypad | Yes |
| Pointing device | Touchpad |
| Software | |
| Operating system installed | Endless OS |
| Battery | |
| Battery capacity (Watt-hours) | 36 Wh |
| Number of battery cells | 3 |
| Battery capacity | 36 Wh |
| Weight & dimensions | |
| Weight | 2 kg |
| Height | 27.6 mm |
| Depth | 251.5 mm |
| Width | 381.4 mm |
| Power | |
| AC adapter power | 33 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
| AC adapter output current | 1.75 A |
| Security | |
| Password protection | Yes |
| Password protection type | BIOS, HDD, User |
