ASUS Vivobook Pro M580GD-E4553 - 90NB0HX4-M09060

ASUS Vivobook Pro M580GD-E4553

Product code: 90NB0HX4-M09060

  • đŸ’ģDisplay diagonal: 15.6 inch
  • đŸ”ŗProcessor model: i5-8300H
  • đŸŽĢInternal memory: 8 GB
  • 🎮On-board graphics adapter model: Intel UHD Graphics 630
  • 🎮Discrete graphics adapter model: NVIDIA GeForce GTX 1050
  • đŸ’ŊTotal storage capacity: 1.13 TB
  • âš–ī¸Weight:
📊 Add to compare

As an Amazon Associate I earn from qualifying purchases.

Specifications
Design
Product colourGrey
Product typeLaptop
Form factorClamshell
Display
Display diagonal15.6 inch
Dual-screenNo
Display surfaceMatt
HD typeFull HD
LED backlightYes
Display resolution1920 x 1080 pixels
Native aspect ratio16:9
BrandASUS
FamilyVivobook
SeriesPro
Model nameM580GD-E4553
Part Number90NB0HX4-M09060
Release Date10 October 2019
Processor
Processor manufacturerIntel
Processor familyIntel Core i5
Processor frequency2.3 GHz
Motherboard chipsetIntel HM370
Processor boost frequency4 GHz
Processor codenameCoffee Lake
Thermal Design Power (TDP)45 W
Processor modeli5-8300H
Processor cores4
Processor threads8
Processor cache8 MB
Processor lithography14 nm
Processor socketBGA 1440
Processor generation8th gen Intel Core i5
Memory
Internal memory8 GB
Memory slots2x SO-DIMM
Maximum internal memory16 GB
Graphics
On-board graphics adapterY
On-board graphics adapter familyIntel UHD Graphics
Discrete graphics memory typeGDDR5
On-board graphics adapter DirectX version12.0
Discrete graphics adapterY
On-board graphics adapter modelIntel UHD Graphics 630
Discrete graphics adapter modelNVIDIA GeForce GTX 1050
On-board graphics adapter base frequency350 MHz
On-board graphics adapter dynamic frequency (max)1000 MHz
Maximum on-board graphics adapter memory64 GB
On-board graphics adapter OpenGL version4.5
On-board graphics cardYes
Discrete graphics cardYes
Discrete graphics card modelNVIDIA GeForce GTX 1050
On-board graphics card modelIntel UHD Graphics 630
On-board graphics card familyIntel UHD Graphics
On-board graphics card base frequency350 MHz
On-board graphics card dynamic frequency (max)1000 MHz
Maximum on-board graphics card memory64 GB
On-board graphics card DirectX version12.0
On-board graphics card OpenGL version4.5
On-board graphics card ID0x3E9B
Storage
Total storage capacity1.13 TB
Number of SSDs installed1
SSD capacity128 GB
Total SSDs capacity128 GB
Number of HDDs installed1
HDD capacity1 TB
HDD speed5400 RPM
SSD interfaceSATA III
HDD interfaceSATA
Total HDDs capacity1 TB
Compatible memory cardsSD, SDXC
Card reader integratedYes
Storage mediaHDD+SSD
Networking
Ethernet LANYes
Ethernet LAN data rates10, 100, 1000 Mbit/s
Wi-FiYes
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Antenna type2x2
BluetoothYes
Bluetooth version4.2
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
Combo headphone/mic portYes
USB 2.0 ports quantity2
HDMI ports quantity1
Ethernet LAN (RJ-45) ports1
VGA (D-Sub) ports quantity1
Audio
Built-in microphoneYes
Audio systemSonicMaster
Camera
Front cameraYes
Keyboard
Numeric keypadYes
Windows keysYes
Pointing deviceTouchpad
Software
Operating system installedNo
Battery
Battery technologyLithium Polymer (LiPo)
Battery capacity (Watt-hours)47 Wh
Number of battery cells3
Battery capacity47 Wh
Weight & dimensions
Height19.2 mm
Depth256 mm
Width380 mm
Power
AC adapter power120 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
AC adapter output voltage19 V
AC adapter output current6.3 A
Security
Cable lock slotYes
Cable lock slot typeKensington
