ASUS 507MA-BR103T - F507MA-BR103T
ASUS 507MA-BR103T
Product code: F507MA-BR103T
- đģDisplay diagonal: 15.6 inch
- đŗProcessor model: N4000
- đĢInternal memory: 4 GB
- đŽOn-board graphics adapter model: Intel UHD Graphics 600
- đŽDiscrete graphics adapter model: Not available
- đŊTotal storage capacity: 128 GB
- âī¸Weight: 1.68 kg
đ Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Blue, Silver |
| Product type | Laptop |
| Form factor | Clamshell |
| Display | |
| Display diagonal | 15.6 inch |
| Display surface | Matt |
| Aspect ratio | 16:9 |
| HD type | HD |
| LED backlight | Yes |
| Touchscreen | No |
| Display resolution | 1366 x 768 pixels |
| Native aspect ratio | 16:9 |
| Brand | ASUS |
| Model name | 507MA-BR103T |
| Part Number | F507MA-BR103T |
| Release Date | 19 March 2020 |
| EAN/UPC code | 4718017558662 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Celeron |
| Processor frequency | 1.1 GHz |
| Processor boost frequency | 2.6 GHz |
| Processor codename | Gemini Lake |
| Thermal Design Power (TDP) | 6 W |
| Processor model | N4000 |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor cache | 4 MB |
| Processor lithography | 14 nm |
| Processor socket | BGA 1090 |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 4 GB |
| Memory slots | 1x SO-DIMM |
| Maximum internal memory | 8 GB |
| Graphics | |
| On-board graphics adapter | Y |
| On-board graphics adapter family | Intel UHD Graphics |
| Number of execution units | 12 |
| Discrete graphics adapter | N |
| On-board graphics adapter model | Intel UHD Graphics 600 |
| Discrete graphics adapter model | Not available |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel UHD Graphics 600 |
| On-board graphics card family | Intel UHD Graphics |
| On-board graphics card base frequency | 200 MHz |
| On-board graphics card dynamic frequency (max) | 650 MHz |
| Maximum on-board graphics card memory | 8 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card ID | 0x3185 |
| On-board graphics card burst frequency | 650 MHz |
| Storage | |
| Total storage capacity | 128 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 128 GB |
| Total SSDs capacity | 128 GB |
| Compatible memory cards | MMC, SD |
| Card reader integrated | Yes |
| Storage media | SSD |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | No |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Charging port type | DC-in jack |
| Combo headphone/mic port | Yes |
| USB 2.0 ports quantity | 2 |
| HDMI ports quantity | 1 |
| Audio | |
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | SonicMaster |
| Camera | |
| Front camera | Yes |
| Keyboard | |
| Numeric keypad | Yes |
| Island-style keyboard | Yes |
| Pointing device | Touchpad |
| Software | |
| Operating system installed | Windows 10 Home |
| Operating system architecture | 64-bit |
| Battery | |
| Number of battery cells | 3 |
| Weight & dimensions | |
| Weight | 1.68 kg |
| Height | 21.9 mm |
| Depth | 266 mm |
| Width | 365 mm |
| Power | |
| AC adapter power | 33 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
| AC adapter output current | 1.75 A |
| Security | |
| Password protection | Yes |
| Password protection type | BIOS, HDD, User |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
