ASUS 509MA-BR263T - F509MA-BR263T
ASUS 509MA-BR263T
Product code: F509MA-BR263T
- đģDisplay diagonal: 15.6 inch
- đŗProcessor model: N4020
- đĢInternal memory: 4 GB
- đŽOn-board graphics adapter model: Intel UHD Graphics 600
- đŽDiscrete graphics adapter model: Not available
- đŊTotal storage capacity: 256 GB
- âī¸Weight: 1.9 kg
đ Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Silver |
| Product type | Laptop |
| Form factor | Clamshell |
| Display | |
| Display diagonal | 15.6 inch |
| Aspect ratio | 16:9 |
| HD type | HD |
| LED backlight | Yes |
| Touchscreen | No |
| Display resolution | 1366 x 768 pixels |
| Native aspect ratio | 16:9 |
| Brand | ASUS |
| Model name | 509MA-BR263T |
| Part Number | F509MA-BR263T |
| Release Date | 02 June 2020 |
| EAN/UPC code | 4718017740265 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Celeron N |
| Processor frequency | 1.1 GHz |
| Processor boost frequency | 2.8 GHz |
| Processor codename | Gemini Lake Refresh |
| Thermal Design Power (TDP) | 6 W |
| Processor model | N4020 |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor cache | 4 MB |
| Processor lithography | 14 nm |
| Processor socket | BGA 1090 |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 4 GB |
| Memory form factor | SO-DIMM |
| Maximum internal memory | 8 GB |
| Graphics | |
| On-board graphics adapter | Y |
| On-board graphics adapter family | Intel UHD Graphics |
| On-board graphics adapter burst frequency | 650 MHz |
| Number of execution units | 12 |
| On-board graphics adapter DirectX version | 12.0 |
| Discrete graphics adapter | N |
| On-board graphics adapter model | Intel UHD Graphics 600 |
| Discrete graphics adapter model | Not available |
| On-board graphics adapter base frequency | 200 MHz |
| Maximum on-board graphics adapter memory | 8 GB |
| On-board graphics adapter OpenGL version | 4.4 |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel UHD Graphics 600 |
| On-board graphics card family | Intel UHD Graphics |
| On-board graphics card base frequency | 200 MHz |
| Maximum on-board graphics card memory | 8 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.4 |
| On-board graphics card ID | 0x3185 |
| On-board graphics card burst frequency | 650 MHz |
| Storage | |
| Total storage capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| Total SSDs capacity | 256 GB |
| SSD interface | NVMe, PCI Express |
| SSD form factor | M.2 |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
| Storage media | SSD |
| NVMe | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | No |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Bluetooth | Yes |
| Bluetooth version | 4.1 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Combo headphone/mic port | Yes |
| USB 2.0 ports quantity | 2 |
| HDMI ports quantity | 1 |
| Audio | |
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | SonicMaster |
| Camera | |
| Front camera | Yes |
| Front camera resolution | 640 x 480 pixels |
| Front camera resolution (numeric) | 0.3 MP |
| Keyboard | |
| Numeric keypad | Yes |
| Island-style keyboard | Yes |
| Full-size keyboard | Yes |
| Pointing device | Touchpad |
| Software | |
| Operating system installed | Windows 10 Home |
| Operating system architecture | 64-bit |
| Trial software | Microsoft Office 365 |
| Windows 11 free upgrade | Yes |
| Battery | |
| Number of battery cells | 2 |
| Weight & dimensions | |
| Weight | 1.9 kg |
| Height | 22.9 mm |
| Depth | 235 mm |
| Width | 360 mm |
| Power | |
| AC adapter power | 33 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| Security | |
| Password protection | Yes |
