ASUS 46CM-WX180H - S46CM-WX180H
ASUS 46CM-WX180H
Product code: S46CM-WX180H
- đģDisplay diagonal: 14 inch
- đŗProcessor model: i5-3317U
- đĢInternal memory: 4 GB
- đŽOn-board graphics adapter model: Intel HD Graphics 4000
- đŽDiscrete graphics adapter model: NVIDIA GeForce GT 635M
- đŊTotal storage capacity: 500 GB
- âī¸Weight: 2 kg
đ Add to compare
Specifications
| Design | |
|---|---|
| Product colour | Black, Grey |
| Colour of product | Black, Grey |
| Product type | Notebook |
| Form factor | Clamshell |
| Display | |
| Display diagonal | 14 inch |
| Aspect ratio | 16:9 |
| HD type | HD |
| LED backlight | Y |
| Touchscreen | N |
| Display resolution | 1366 x 768 pixels |
| Native aspect ratio | 16:9 |
| Brand | ASUS |
| Model name | 46CM-WX180H |
| Part Number | S46CM-WX180H |
| Release Date | 18 August 2017 |
|
|
|
| Processor | |
| Processor series | Intel Core i5-3300 Mobile series |
| Processor manufacturer | Intel |
| Processor family | Intel Core i5 |
| Processor frequency | 1.7 GHz |
| Motherboard chipset | Intel HM76 Express |
| Processor boost frequency | 2.6 GHz |
| Processor codename | Ivy Bridge |
| Thermal Design Power (TDP) | 17 W |
| Processor model | i5-3317U |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor cache | 3 MB |
| Processor lithography | 22 nm |
| Processor socket | BGA 1023 |
| Processor generation | 3rd gen Intel Core i5 |
| Memory | |
| Internal memory type | DDR3-SDRAM |
| Internal memory | 4 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 1600 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 8 GB |
| Graphics | |
| On-board graphics adapter | Y |
| Discrete graphics memory type | GDDR3 |
| Discrete graphics adapter | Y |
| On-board graphics adapter model | Intel HD Graphics 4000 |
| Discrete graphics adapter model | NVIDIA GeForce GT 635M |
| On-board graphics adapter base frequency | 350 MHz |
| On-board graphics adapter dynamic frequency (max) | 1050 MHz |
| Number of displays supported (on-board graphics) | 3 |
| Discrete graphics adapter memory | 2 GB |
| On-board graphics card | Y |
| Discrete graphics card | Y |
| Discrete graphics card model | NVIDIA GeForce GT 635M |
| On-board graphics card model | Intel HD Graphics 4000 |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1050 MHz |
| On-board graphics card ID | 0x166 |
| Discrete graphics card memory | 2 GB |
| Storage | |
| Total storage capacity | 500 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 24 GB |
| Number of HDDs installed | 1 |
| HDD capacity | 500 GB |
| HDD speed | 5400 RPM |
| HDD size | 2.5" |
| Hard drive speed | 5400 RPM |
| Hard drive size | 2.5" |
| Hard drive capacity | 500 GB |
| Number of hard drives installed | 1 |
| Compatible memory cards | SD |
| Solid-state drive capacity | 24 GB |
| Card reader integrated | Y |
| Storage media | HDD+SSD |
| Networking | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Wi-Fi | Y |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| 4G | N |
| 3G | N |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Charging port type | DC-in jack |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 1 |
| DVI port | N |
| Combo headphone/mic port | Y |
| DC-in jack | Y |
| USB 2.0 ports quantity | 2 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Audio | |
| Built-in microphone | Y |
| Audio system | SonicMaster |
| Camera | |
| Front camera | Y |
| Keyboard | |
| Numeric keypad | N |
| Windows keys | Y |
| Pointing device | Touchpad |
| Software | |
| Operating system installed | Windows 8 |
| Drivers included | Y |
| Battery | |
| Number of battery cells | 4 |
| Battery capacity | 2950 mAh |
| Battery capacity (Watt hours) | 44 Wh |
| Weight & dimensions | |
| Weight | 2 kg |
| Height | 21 mm |
| Depth | 248 mm |
| Width | 348 mm |
| Power | |
| AC adapter power | 65 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
| AC adapter output current | 3.42 A |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
