ASUS 540SA-RS01 - 90NB0B31-M01140
ASUS 540SA-RS01
Product code: 90NB0B31-M01140
- đģDisplay diagonal: 15.6 inch
- đŗProcessor model: N3050
- đĢInternal memory: 4 GB
- đŽOn-board graphics adapter model: Intel HD Graphics
- đŽDiscrete graphics adapter model: Not available
- đŊTotal storage capacity: 500 GB
- âī¸Weight: 1.9 kg
đ Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Black, Chocolate |
| Colour of product | Black, Chocolate |
| Product type | Notebook |
| Form factor | Clamshell |
| Display | |
| Display diagonal | 15.6 inch |
| Display surface | Gloss |
| Aspect ratio | 16:9 |
| LED backlight | Y |
| Touchscreen | N |
| Display resolution | 1366 x 768 pixels |
| Native aspect ratio | 16:9 |
| Brand | ASUS |
| Model name | 540SA-RS01 |
| Part Number | 90NB0B31-M01140 |
| Release Date | 05 July 2016 |
| EAN/UPC code | 0889349266397, 889349266397, 0600607441109, 600607441109 |
|
|
|
| Processor | |
| Processor series | Intel Celeron N3000 series |
| Processor manufacturer | Intel |
| Processor family | Intel Celeron |
| Processor frequency | 1.6 GHz |
| Processor boost frequency | 2.16 GHz |
| Processor codename | Braswell |
| Thermal Design Power (TDP) | 6 W |
| Processor model | N3050 |
| Processor cores | 2 |
| Processor threads | 2 |
| Processor cache | 2 MB |
| Processor lithography | 14 nm |
| Processor socket | BGA 1170 |
| Memory | |
| Internal memory type | DDR3L-SDRAM |
| Internal memory | 4 GB |
| Memory clock speed | 1600 MHz |
| Maximum internal memory | 8 GB |
| Graphics | |
| On-board graphics adapter | Y |
| On-board graphics adapter family | Intel HD Graphics |
| On-board graphics adapter burst frequency | 600 MHz |
| Number of execution units | 12 |
| Graphics adapter Open GL support | Y |
| On-board graphics adapter DirectX version | Y |
| Discrete graphics adapter | N |
| On-board graphics adapter model | Intel HD Graphics |
| Discrete graphics adapter model | Not available |
| On-board graphics adapter base frequency | 320 MHz |
| Maximum on-board graphics adapter memory | 8 GB |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card | Y |
| Discrete graphics card | N |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel HD Graphics |
| On-board graphics card family | Intel HD Graphics |
| On-board graphics card base frequency | 320 MHz |
| Maximum on-board graphics card memory | 8 GB |
| On-board graphics card DirectX version | Y |
| On-board graphics card burst frequency | 600 MHz |
| Graphics card Open GL support | Y |
| Storage | |
| Total storage capacity | 500 GB |
| Number of HDDs installed | 1 |
| HDD capacity | 500 GB |
| HDD speed | 5400 RPM |
| Hard drive speed | 5400 RPM |
| Hard drive capacity | 500 GB |
| Number of hard drives installed | 1 |
| Compatible memory cards | SD, SDHC, SDXC |
| Card reader integrated | Y |
| Storage media | HDD |
| Optical drive | |
| Optical drive type | DVD Super Multi DL |
| Networking | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10, 100 Mbit/s |
| Wi-Fi | Y |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth | Y |
| Bluetooth version | 4.0 |
| 4G | N |
| 3G | N |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Total number of SATA connectors | 2 |
| Charging port type | DC-in jack |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 1 |
| Number of SATA III connectors | 2 |
| DVI port | N |
| Docking connector | N |
| USB 3.0 (3.1 Gen 1) Type-C ports quantity | 1 |
| Combo headphone/mic port | Y |
| DC-in jack | Y |
| USB 2.0 ports quantity | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Audio | |
| Built-in microphone | Y |
| Camera | |
| Front camera | Y |
| Keyboard | |
| Numeric keypad | Y |
| Full-size keyboard | Y |
| Windows keys | Y |
| Pointing device | Touchpad |
| Software | |
| Operating system installed | Windows 10 Home |
| Operating system architecture | 64-bit |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 3 |
| Battery capacity | 33 Wh |
| Battery capacity (Watt hours) | 33 Wh |
| Weight & dimensions | |
| Weight | 1.9 kg |
| Height | 25.4 mm |
| Depth | 251.5 mm |
| Width | 381.4 mm |
| Power | |
| AC adapter power | 45 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
| AC adapter output current | 2.37 A |
| Security | |
| Password protection | Y |
| Password protection type | BIOS, HDD, User |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
