ASUS 54HR-SX336D - X54HR-SX336D
ASUS 54HR-SX336D
Product code: X54HR-SX336D
- đģDisplay diagonal: 15.6 inch
- đŗProcessor model: i3-2370M
- đĢInternal memory: 4 GB
- đŽOn-board graphics adapter model: Intel HD Graphics 3000
- đŽDiscrete graphics adapter model: AMD Radeon HD 7470M
- đŊTotal storage capacity: 500 GB
- âī¸Weight: 2.6 kg
đ Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Black |
| Colour of product | Black |
| Product type | Notebook |
| Form factor | Clamshell |
| Display | |
| Display diagonal | 15.6 inch |
| Aspect ratio | 16:9 |
| HD type | HD |
| LED backlight | Y |
| Touchscreen | N |
| Display resolution | 1366 x 768 pixels |
| Native aspect ratio | 16:9 |
| Brand | ASUS |
| Model name | 54HR-SX336D |
| Part Number | X54HR-SX336D |
| Release Date | 18 August 2017 |
|
|
|
| Processor | |
| Processor series | Intel Core i3-2300 Mobile Series |
| Processor manufacturer | Intel |
| Processor family | Intel Core i3 |
| Processor frequency | 2.4 GHz |
| Motherboard chipset | Intel HM65 Express |
| Processor codename | Sandy Bridge |
| Thermal Design Power (TDP) | 35 W |
| Processor model | i3-2370M |
| Processor cores | 2 |
| Processor threads | 4 |
| Processor cache | 3 MB |
| Processor lithography | 32 nm |
| Processor socket | Socket 988 |
| Processor generation | 2nd gen Intel Core i3 |
| Memory | |
| Internal memory type | DDR3-SDRAM |
| Internal memory | 4 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 1333 MHz |
| Memory slots | 1x SO-DIMM |
| Maximum internal memory | 4 GB |
| Graphics | |
| On-board graphics adapter | Y |
| Discrete graphics memory type | GDDR3 |
| Discrete graphics adapter | Y |
| On-board graphics adapter model | Intel HD Graphics 3000 |
| Discrete graphics adapter model | AMD Radeon HD 7470M |
| On-board graphics adapter base frequency | 650 MHz |
| On-board graphics adapter dynamic frequency (max) | 1150 MHz |
| Number of displays supported (on-board graphics) | 2 |
| Discrete graphics adapter memory | 1 GB |
| On-board graphics card | Y |
| Discrete graphics card | Y |
| Discrete graphics card model | AMD Radeon HD 7470M |
| On-board graphics card model | Intel HD Graphics 3000 |
| On-board graphics card base frequency | 650 MHz |
| On-board graphics card dynamic frequency (max) | 1150 MHz |
| On-board graphics card ID | 0x116 |
| Discrete graphics card memory | 1 GB |
| Storage | |
| Total storage capacity | 500 GB |
| Number of HDDs installed | 1 |
| HDD capacity | 500 GB |
| Hard drive capacity | 500 GB |
| Number of hard drives installed | 1 |
| Compatible memory cards | MMC, MS PRO, Memory Stick (MS), SD |
| Card reader integrated | Y |
| Storage media | HDD |
| Optical drive | |
| Optical drive type | DVD-RW |
| Networking | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Wi-Fi | Y |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| 4G | N |
| 3G | N |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Charging port type | DC-in jack |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 1 |
| Microphone in | Y |
| S/PDIF out port | Y |
| DVI port | N |
| Combo headphone/mic port | Y |
| DC-in jack | Y |
| USB 2.0 ports quantity | 1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Audio | |
| Built-in microphone | Y |
| Speakers manufacturer | Altec Lansing |
| Camera | |
| Front camera | Y |
| Front camera resolution (numeric) | 0.3 MP |
| Keyboard | |
| Numeric keypad | Y |
| Full-size keyboard | Y |
| Windows keys | Y |
| Pointing device | Touchpad |
| Software | |
| Operating system installed | FreeDOS |
| Drivers included | Y |
| Battery | |
| Number of battery cells | 4 |
| Battery capacity | 2600 mAh |
| Battery capacity (Watt hours) | 37 Wh |
| Weight & dimensions | |
| Weight | 2.6 kg |
| Height (rear) | 3.72 cm |
| Height (front) | 3.56 cm |
| Depth | 253 mm |
| Width | 378 mm |
| Power | |
| AC adapter power | 75 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
| AC adapter output current | 3.95 A |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
Comments
jalali REPLY04 Mar 2021 - 18:03
Does this laptop have a SSD slot or do I need to detach my HDD?
