DELL Inspiron 5301 - 5301-6317
DELL Inspiron 5301
Product code: 5301-6317
- 💻Display diagonal: 13.3 inch
- 🔳Processor model: i5-1135G7
- 🎫Internal memory: 8 GB
- 🎮On-board graphics adapter model: Intel Iris Xe Graphics
- 🎮Discrete graphics adapter model: Not available
- 💽Total storage capacity: 256 GB
- ⚖️Weight: 1.23 kg
📊 Add to compare
Specifications
| Design | |
|---|---|
| Product colour | Silver |
| Product type | Laptop |
| Form factor | Clamshell |
| Display | |
| Display diagonal | 13.3 inch |
| Maximum refresh rate | 60 Hz |
| Pixel density | 166 ppi |
| Contrast ratio (typical) | 600:1 |
| Display brightness | 300 cd/m² |
| Panel type | WVA |
| HD type | Full HD |
| LED backlight | Yes |
| Touchscreen | No |
| Display resolution | 1920 x 1080 pixels |
| RGB colour space | sRGB |
| Colour gamut | 95% |
| Native aspect ratio | 16:9 |
| Brand | DELL |
| Family | Inspiron |
| Series | 5000 |
| Model name | 5301 |
| Part Number | 5301-6317 |
| Release Date | 26 October 2020 |
| EAN/UPC code | 5397184516317 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core i5 |
| Processor boost frequency | 4.2 GHz |
| Processor model | i5-1135G7 |
| Processor cores | 4 |
| Processor cache | 8 MB |
| Configurable TDP-up frequency | 2.4 GHz |
| Configurable TDP-up | 28 W |
| Processor generation | 11th gen Intel Core i5 |
| Memory | |
| Internal memory type | LPDDR4x-SDRAM |
| Internal memory | 8 GB |
| Memory form factor | On-board |
| Memory clock speed | 4267 MHz |
| Maximum internal memory | 8 GB |
| Graphics | |
| On-board graphics adapter | Y |
| Discrete graphics adapter | N |
| On-board graphics adapter model | Intel Iris Xe Graphics |
| Discrete graphics adapter model | Not available |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel Iris Xe Graphics |
| On-board GPU manufacturer | Intel |
| Storage | |
| Total storage capacity | 256 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 256 GB |
| Total SSDs capacity | 256 GB |
| SSD interface | NVMe, PCI Express |
| SSD form factor | M.2 |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Card reader integrated | Yes |
| Storage media | SSD |
| NVMe | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | No |
| WLAN controller model | Intel Dual Band Wireless-AC 9560 |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB Power Delivery | Y |
| Charging port type | DC-in jack |
| HDMI version | 2.0 |
| Combo headphone/mic port | Yes |
| HDMI ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Power Delivery (USB PD) | Yes |
| Audio | |
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | MaxxAudio Pro |
| Speaker power | 2 W |
| Audio chip | Realtek ALC3204 |
| Speakers manufacturer | Waves |
| Camera | |
| Front camera | Yes |
| Front camera HD type | HD |
| Video capturing speed | 30 fps |
| Front camera resolution | 1280 x 720 pixels |
| Front camera resolution (numeric) | 0.92 MP |
| Keyboard | |
| Numeric keypad | No |
| Keyboard layout | QWERTZ |
| Keyboard backlit | Yes |
| Pointing device | Touchpad |
| Keyboard language | German |
| Software | |
| Operating system installed | Windows 10 Home |
| Operating system architecture | 64-bit |
| Bundled software | Financial Tracker & Retail Information |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery weight | 180 g |
| Battery capacity (Watt-hours) | 40 Wh |
| Number of battery cells | 3 |
| Battery capacity | 40 Wh |
| Battery voltage | 11.4 V |
| Weight & dimensions | |
| Weight | 1.23 kg |
| Height (rear) | 1.58 cm |
| Height (front) | 1.39 cm |
| Depth | 203.4 mm |
| Width | 306 mm |
| Power | |
| AC adapter power | 45 W |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| AC adapter output voltage | 19.5 V |
| AC adapter output current | 2.31 A |
| Security | |
| Fingerprint reader | Yes |
| Password protection | Yes |
| Other features | |
| Anti-glare screen | Yes |
