HP Dragonfly 13.5 - B66TJAT
HP Dragonfly 13.5
Product code: B66TJAT
- 💻Display diagonal: 13.5 inch
- 🔳Processor model: i7-1355U
- 🎫Internal memory: 32 GB
- 🎮On-board graphics adapter model:
- 🎮Discrete graphics adapter model:
- 💽Total storage capacity: 512 GB
- ⚖️Weight: 0.99 kg
📊 Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Blue |
| Product type | Laptop |
| Form factor | Clamshell |
| Market positioning | Premium |
| Original brand name | HP |
| Introduction year | 2025 |
| Display | |
| Display diagonal | 13.5 inch |
| Display brightness | 400 cd/m² |
| Panel type | IPS |
| HD type | WUXGA+ |
| LED backlight | Yes |
| Touchscreen | Yes |
| Display resolution | 1920 x 1280 pixels |
| RGB colour space | sRGB |
| Colour gamut | 100% |
| Native aspect ratio | 3:2 |
| Brand | HP |
| Family | Dragonfly |
| Model name | 13.5 |
| Part Number | B66TJAT |
| Release Date | 20 January 2025 |
| EAN/UPC code | 0198990644912, 198990644912 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core i7 |
| Processor boost frequency | 5 GHz |
| Processor model | i7-1355U |
| Processor cores | 10 |
| Processor threads | 12 |
| Processor cache | 12 MB |
| Processor generation | 13th gen Intel Core i7 |
| Efficient cores | 8 |
| Performance cores | 2 |
| Performance-core Max Turbo Frequency | 5 GHz |
| Efficient-core Max Turbo Frequency | 3.7 GHz |
| Maximum turbo power | 55 W |
| Processor base power | 15 W |
| Memory | |
| Internal memory type | LPDDR5-SDRAM |
| Internal memory | 32 GB |
| Memory form factor | On-board |
| Maximum internal memory | 32 GB |
| Memory layout (slots x size) | Not available |
| ECC | No |
| Non-ECC | Yes |
| Memory data transfer rate | 6400 MT/s |
| Graphics | |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| Storage | |
| Total storage capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| Total SSDs capacity | 512 GB |
| SSD interface | PCI Express |
| Storage media | SSD |
| NVMe | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| HDMI version | 2.1 |
| Combo headphone/mic port | Yes |
| HDMI ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Thunderbolt 4 ports quantity | 2 |
| USB Power Delivery (USB PD) | Yes |
| Audio | |
| Number of built-in speakers | 4 |
| Audio system | Bang & Olufsen |
| Built-in speaker(s) | Yes |
| Camera | |
| Front camera | Yes |
| Infrared (IR) camera | Yes |
| Front camera resolution (numeric) | 5 MP |
| Keyboard | |
| Numeric keypad | No |
| Spill-resistant keyboard | Yes |
| Keyboard special features | Spill-resistant |
| Island-style keyboard | Yes |
| Keyboard backlit | Yes |
| Pointing device | Clickpad |
| Input device model | HP Premium Keyboard |
| Software | |
| Operating system installed | Windows 11 Pro |
| Pre-installed software | HP Connection Optimizer; HP Hotkey Support; HP Support Assistant; HP Easy Clean; HP Power Manager; myHP; HP Privacy Settings; HP Notifications; HP PC Hardware Diagnostics Windows; HP Services Scan; HP Smart Support (download) |
| Bundled software | HP Wolf Pro Security Edition (1 year) |
| Battery | |
| Battery technology | Lithium Polymer (LiPo) |
| Battery weight | 204 g |
| Number of battery cells | 6 |
| Battery capacity | 68 Wh |
| Weight & dimensions | |
| Weight | 0.99 kg |
| Height | 16.4 mm |
| Depth | 220.4 mm |
| Width | 297.4 mm |
| Power | |
| AC adapter power | 65 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| USB Type-C charging port | Yes |
| Security | |
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | BIOS, Power on, User |
| Trusted Platform Module (TPM) version | 2.0 |
| Brand-specific features | |
| HP Security tools | Absolute persistence module; HP Secure Erase; HP Sure Click; HP Sure Sense; BIOS Update via Network; HP Sure Admin; HP BIOSphere Gen6; TPM 2.0 embedded security chip (Common Criteria EAL4+ and FIPS 140-2 Level 2 Certified); HP Sure Start Gen7; HP Wake on WLAN; HP Tamper Lock; HP Sure Run Gen5; HP Sure Recover Gen5; Secured-Core PC Enable |
| HP Management tools | HP Client Management Script Library (download); HP Driver Packs (download); HP Client Catalog (download); HP Manageability Integration Kit Gen4 (download); HP Image Assistant Gen5 (download); HP Patch Assistant (download); HP Cloud Recovery; HP Connect for Microsoft Endpoint Manager |
| HP Connection Optimizer | Yes |
| HP segment | Business |
| HP Support Assistant | Yes |
| HP speaker type | HP Quad Speakers |
| HP GTIN (EAN/UPC) | 198990644912 |
| Other features | |
| Display diagonal (metric) | 34.3 cm |
| Anti-glare screen | Yes |
| Harmonized System (HS) code | 8471300000 |
| Manufacturer warranty | 1-year warranty and 90 day software limited warranty options depending on country. Batteries have a default one year limited warranty. |
| Sustainability | |
| Sustainable technologies and materials | Low Halogen; Bulk packaging available; Molded paper pulp cushion inside box is 100% sustainably sourced and recyclable; Outside box and corrugated cushions are 100% sustainably sourced and recyclable; 20% post-consumer recycled plastic; Ocean-bound plastic in speaker enclosure(s); 85% recycled metal |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
