HP OMEN MAX 16-ah0023nb - BG9G3EA#UUG
HP OMEN MAX 16-ah0023nb
Product code: BG9G3EA#UUG
- 💻Display diagonal: 16 inch
- 🔳Processor model: 275HX
- 🎫Internal memory: 32 GB
- 🎮On-board graphics adapter model:
- 🎮Discrete graphics adapter model:
- 💽Total storage capacity: 1 TB
- ⚖️Weight: 2.49 kg
📊 Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Black |
| Product type | Laptop |
| Form factor | Clamshell |
| Market positioning | Gaming |
| Original brand name | HP |
| Introduction year | 2025 |
| Display | |
| Display diagonal | 16 inch |
| Display bezel technology | Micro-Edge |
| Maximum refresh rate | 240 Hz |
| Display response rise/fall | 3 ms |
| Display brightness | 500 cd/m² |
| Panel type | IPS |
| HD type | WQXGA |
| LED backlight | Yes |
| Touchscreen | No |
| Display resolution | 2560 x 1600 pixels |
| RGB colour space | sRGB |
| Colour gamut | 100% |
| Native aspect ratio | 16:10 |
| Low Blue Light technology | Yes |
| Brand | HP |
| Family | OMEN MAX |
| Model name | 16-ah0023nb |
| Part Number | BG9G3EA#UUG |
| EAN/UPC code | 0199251101731, 199251101731 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 9 |
| Processor frequency | 2.7 GHz |
| Motherboard chipset | Intel HM870 |
| Processor boost frequency | 5.4 GHz |
| Processor model | 275HX |
| Processor cores | 24 |
| Processor threads | 24 |
| Processor cache | 36 MB |
| Processor generation | Intel Core Ultra (Series 2) |
| Efficient-core base frequency | 2.1 GHz |
| Efficient cores | 16 |
| Performance cores | 8 |
| Performance-core Max Turbo Frequency | 5.4 GHz |
| Efficient-core Max Turbo Frequency | 4.6 GHz |
| Maximum turbo power | 160 W |
| Processor base power | 55 W |
| Performance-core base frequency | 2.7 GHz |
| Memory | |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 32 GB |
| Memory form factor | SO-DIMM |
| Memory slots | 2x SO-DIMM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots (available) | 2 |
| Memory data transfer rate | 5600 MT/s |
| Graphics | |
| NVIDIA G-SYNC | Yes |
| Discrete graphics memory type | GDDR7 |
| Discrete GPU manufacturer | NVIDIA |
| On-board graphics card | Yes |
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce RTX 5070 |
| On-board graphics card model | Intel Graphics |
| On-board graphics card family | Intel Graphics |
| Discrete graphics card memory | 8 GB |
| On-board GPU manufacturer | Intel |
| Storage | |
| Total storage capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| Total SSDs capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| SSD form factor | M.2 |
| Storage media | SSD |
| NVMe | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| WLAN controller model | Intel Wi-Fi 7 BE200 |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI version | 2.1 |
| USB Sleep-and-Charge ports | 2 |
| Combo headphone/mic port | Yes |
| DC-in jack | Yes |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Sleep-and-Charge | Yes |
| Thunderbolt 4 ports quantity | 2 |
| USB Power Delivery (USB PD) | Yes |
| Audio | |
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | DTS:X Ultra |
| Number of microphones | 2 |
| Built-in speaker(s) | Yes |
| Camera | |
| Front camera | Yes |
| Privacy camera | Yes |
| Infrared (IR) camera | Yes |
| Front camera HD type | Full HD |
| Privacy type | Privacy shutter |
| Keyboard | |
| Numeric keypad | Yes |
| Full-size keyboard | Yes |
| Keyboard layout | AZERTY |
| Keyboard backlit | Yes |
| Pointing device | Touchpad |
| Keyboard backlit zone | 4-zone RGB |
| Keyboard colour name | Shadow black |
| Performance | |
| Temperature sensor | Yes |
| Software | |
| Operating system installed | Windows 11 Home |
| Battery | |
| Battery technology | Lithium Polymer (LiPo) |
| Number of battery cells | 6 |
| Battery capacity | 83 Wh |
| Fast charging | Yes |
| Fast charging time (50%) | 30 min |
| Weight & dimensions | |
| Weight | 2.49 kg |
| Height (rear) | 2.45 cm |
| Height (front) | 2.29 cm |
| Depth | 269 mm |
| Width | 356.5 mm |
| Power | |
| AC adapter power | 280 W |
| AC adapter frequency | 50 - 60 Hz |
| AC adapter input voltage | 100 - 240 V |
| Security | |
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | BIOS, Power on, User |
| Brand-specific features | |
| HP segment | Home |
| HP Audio Boost | Yes |
| HP speaker type | HP Dual Speakers |
| HP Imagepad | Yes |
| HP front camera | HP TrueVision FHD IR |
| HP Artificial Intelligence | AI PC |
| Other features | |
| Display diagonal (metric) | 40.6 cm |
| Anti-glare screen | Yes |
| Neural processor unit (NPU) | |
| Neural processor unit (NPU) | Intel AI Boost |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to | 36 TOPs |
| NPU performance up to | 13 TOPs |
| GPU performance up to | 8 TOPs |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
Download drivers: ➡️ HP OMEN MAX 16-ah0023nb BG9G3EA#UUG Drivers Windows 10 - Autodetect drivers
