HP ZBook 14u G6 - 7QG66PA
HP ZBook 14u G6
Product code: 7QG66PA
- 💻Display diagonal: 14 inch
- 🔳Processor model: i7-8565U
- 🎫Internal memory: 16 GB
- 🎮On-board graphics adapter model:
- 🎮Discrete graphics adapter model:
- 💽Total storage capacity: 512 GB
- ⚖️Weight: 1.48 kg
📊 Add to compare
Specifications
| Design | |
|---|---|
| Product colour | Graphite |
| Product type | Mobile workstation |
| Form factor | Clamshell |
| Market positioning | Performance |
| Display | |
| Display diagonal | 14 inch |
| sRGB coverage (typical) | 72% |
| NTSC coverage (typical) | 45% |
| Display brightness | 250 cd/m² |
| Panel type | IPS |
| HD type | Full HD |
| LED backlight | Yes |
| Touchscreen | No |
| Display resolution | 1920 x 1080 pixels |
| RGB colour space | NTSC |
| Colour gamut | 45% |
| Native aspect ratio | 16:9 |
| Brand | HP |
| Family | ZBook |
| Series | 14u |
| Model name | 14u G6 |
| Part Number | 7QG66PA |
| Release Date | 31 May 2019 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core i7 |
| Processor frequency | 1.8 GHz |
| Processor boost frequency | 4.6 GHz |
| Processor model | i7-8565U |
| Processor cores | 4 |
| Processor cache | 8 MB |
| Configurable TDP-up frequency | 2 GHz |
| Configurable TDP-up | 25 W |
| Processor generation | 8th gen Intel Core i7 |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 16 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 2400 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 64 GB |
| Memory layout (slots x size) | 1 x 16 GB |
| Graphics | |
| Discrete graphics memory type | GDDR5 |
| On-board graphics card | Yes |
| Discrete graphics card | Yes |
| Discrete graphics card model | AMD Radeon Pro WX 3200 |
| On-board graphics card model | Intel UHD Graphics |
| Discrete graphics card memory | 4 GB |
| Storage | |
| Total storage capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| Total SSDs capacity | 512 GB |
| SSD interface | NVMe, PCI Express |
| SSD form factor | M.2 |
| Card reader integrated | No |
| Storage media | SSD |
| NVMe | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| WLAN controller model | Intel Dual Band Wireless-AC 9560 |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| 4G standard | LTE-A |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI version | 1.4b |
| Docking connector | Yes |
| Combo headphone/mic port | Yes |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Thunderbolt 3 ports quantity | 1 |
| Thunderbolt version | 3 |
| Audio | |
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | Bang & Olufsen |
| Camera | |
| Front camera | Yes |
| Keyboard | |
| Numeric keypad | No |
| Spill-resistant keyboard | Yes |
| Island-style keyboard | Yes |
| Full-size keyboard | Yes |
| Keyboard backlit | Yes |
| Pointing device | Clickpad |
| Software | |
| Operating system installed | Windows 10 Pro |
| Operating system architecture | 64-bit |
| Battery | |
| Battery technology | Lithium Polymer (LiPo) |
| Battery capacity (Watt-hours) | 50 Wh |
| Number of battery cells | 3 |
| Battery capacity | 50 Wh |
| Fast charging | Yes |
| Fast charging time (50%) | 30 min |
| Weight & dimensions | |
| Weight | 1.48 kg |
| Height | 17.9 mm |
| Depth | 234.3 mm |
| Width | 326 mm |
| Power | |
| AC adapter power | 65 W |
| Security | |
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | Power on |
| Brand-specific features | |
| HP Smart AC Adapter | Yes |
| HP segment | Business |
| HP speaker type | HP Dual Speakers |
