HP ZBook Studio x360 G5 Thunderbolt Dock 230W G2 VISA - 5CE49PA-DOCK-VISA
HP ZBook Studio x360 G5 Thunderbolt Dock 230W G2 VISA
Product code: 5CE49PA-DOCK-VISA
- đģDisplay diagonal: 15.6 inch
- đŗProcessor model: E-2176M
- đĢInternal memory: 16 GB
- đŽOn-board graphics adapter model: Intel UHD Graphics P630
- đŽDiscrete graphics adapter model: NVIDIA Quadro P1000
- đŊTotal storage capacity: 512 GB
- âī¸Weight: 2.26 kg
đ Add to compare
Specifications
| Design | |
|---|---|
| Product colour | Silver |
| Product type | Mobile workstation |
| Form factor | Convertible (Folder) |
| Display | |
| Display diagonal | 15.6 inch |
| Dual-screen | No |
| Panel type | IPS |
| Touch technology | Multi-touch |
| HD type | Full HD |
| LED backlight | Yes |
| Touchscreen | Yes |
| Display resolution | 1920 x 1080 pixels |
| Native aspect ratio | 16:9 |
| Brand | HP |
| Family | ZBook |
| Series | Studio x360 |
| Model name | Studio x360 G5 + Thunderbolt Dock 230W G2 + VISA |
| Part Number | 5CE49PA-DOCK-VISA |
| Release Date | 26 April 2019 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Xeon |
| Processor frequency | 2.7 GHz |
| Motherboard chipset | Intel CM246 |
| Processor boost frequency | 4.4 GHz |
| Processor codename | Coffee Lake |
| Thermal Design Power (TDP) | 45 W |
| Processor model | E-2176M |
| Processor cores | 6 |
| Processor threads | 12 |
| Processor cache | 12 MB |
| Processor lithography | 14 nm |
| Processor socket | BGA 1440 |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 16 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 2666 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 32 GB |
| Memory layout (slots x size) | 1 x 16 GB |
| Graphics | |
| On-board graphics adapter | Y |
| On-board graphics adapter family | Intel UHD Graphics |
| Discrete graphics memory type | GDDR5 |
| On-board graphics adapter DirectX version | 12.0 |
| Discrete graphics adapter | Y |
| On-board graphics adapter model | Intel UHD Graphics P630 |
| Discrete graphics adapter model | NVIDIA Quadro P1000 |
| On-board graphics adapter base frequency | 350 MHz |
| On-board graphics adapter dynamic frequency (max) | 1200 MHz |
| Maximum on-board graphics adapter memory | 64 GB |
| On-board graphics adapter OpenGL version | 4.5 |
| Discrete graphics adapter memory | 4 GB |
| On-board graphics card | Yes |
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA Quadro P1000 |
| On-board graphics card model | Intel UHD Graphics P630 |
| On-board graphics card family | Intel UHD Graphics |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1200 MHz |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card ID | 0x3E9B |
| Discrete graphics card memory | 4 GB |
| Storage | |
| Total storage capacity | 512 GB |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| Total SSDs capacity | 512 GB |
| SSD interface | NVMe 3.0, PCI Express |
| Compatible memory cards | SD, SDHC, SDXC |
| Card reader integrated | Yes |
| Storage media | SSD |
| NVMe | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | No |
| Wi-Fi | Yes |
| WLAN controller model | Intel Dual Band Wireless-AC 9560 |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Antenna type | 2x2 |
| Bluetooth | Yes |
| Bluetooth version | 5.0 |
| WWAN | Installed |
| 4G standard | LTE |
| 3G standards | HSPA+ |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 2 |
| Charging port type | DC-in jack |
| HDMI version | 2.0 |
| USB Sleep-and-Charge ports | 1 |
| Combo headphone/mic port | Yes |
| HDMI ports quantity | 1 |
| Thunderbolt 3 ports quantity | 2 |
| USB Sleep-and-Charge | Yes |
| Audio | |
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | Bang & Olufsen |
| Number of microphones | 2 |
| Camera | |
| Front camera | Yes |
| Infrared (IR) camera | Yes |
| Front camera HD type | HD |
| Front camera signal format | 720p |
| Keyboard | |
| Numeric keypad | No |
| Spill-resistant keyboard | Yes |
| Island-style keyboard | Yes |
| Full-size keyboard | Yes |
| Keyboard backlit | Yes |
| Pointing device | Clickpad |
| Software | |
| Operating system installed | Windows 10 Pro |
| Operating system architecture | 64-bit |
| Battery | |
| Battery technology | Lithium Polymer (LiPo) |
| Battery capacity (Watt-hours) | 95.6 Wh |
| Number of battery cells | 6 |
| Battery life (max) | 16.5 h |
| Battery capacity | 95.6 Wh |
| Weight & dimensions | |
| Weight | 2.26 kg |
| Height (rear) | 1.87 cm |
| Height (front) | 8.8 mm |
| Depth | 254 mm |
| Width | 360 mm |
| Power | |
| AC adapter power | 150 W |
| Security | |
| Cable lock slot | Yes |
| Fingerprint reader | Yes |
| Trusted Platform Module (TPM) | Yes |
| Password protection | Yes |
| Password protection type | Power on |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
