HP ZBook Studio G5 - 4DB77AW
HP ZBook Studio G5
Product code: 4DB77AW
- đģDisplay diagonal: 15.6 inch
- đŗProcessor model: E-2176M
- đĢInternal memory: 16 GB
- đŽOn-board graphics adapter model: Intel UHD Graphics P630
- đŽDiscrete graphics adapter model:
- đŊTotal storage capacity: 512 GB
- âī¸Weight: 2 kg
đ Add to compare
Specifications
| Design | |
|---|---|
| Product colour | Silver |
| Product type | Mobile workstation |
| Form factor | Clamshell |
| Display | |
| Display diagonal | 15.6 inch |
| Display brightness | 400 cd/mò |
| Panel type | IPS |
| Display surface | Matt |
| Aspect ratio | 16:9 |
| HD type | Full HD |
| LED backlight | Y |
| Touchscreen | N |
| Display resolution | 1920 x 1080 pixels |
| Brand | HP |
| Family | ZBook |
| Series | Studio |
| Model name | Studio G5 |
| Part Number | 4DB77AW |
| Release Date | 01 June 2019 |
| EAN/UPC code | 0192545505383, 0192545505178, 0192545505352, 0192545505598, 0192545505604, 0192545505314, 0192545505246, 0192545505666, 0192545505499, 0192545505291, 0192545505147, 0192545505512, 0192545505345, 0192545505550, 0192545505260, 0192545505239, 0192545505420, 0192545505369, 0192545505680, 0192545505116, 0192545505482, 0192545505406, 0192545505451, 0192545504362, 0192545505611, 0192545505208, 0192545505574, 0192545505505, 0192545505567, 0192545505444, 0192545505161, 0192545505659, 0192545505758, 0192545505390, 0192545505307, 0192545505475, 0192545505581, 0192545505468 |
|
|
|
| Processor | |
| Processor family | Intel Xeon |
| Processor frequency | 2.70 GHz |
| Processor boost frequency | 4.40 GHz |
| Processor codename | Coffee Lake |
| Thermal Design Power (TDP) | 45 W |
| Processor model | E-2176M |
| Processor cores | 6 |
| Processor threads | 12 |
| Processor cache | 12 MB |
| Processor lithography | 14 nm |
| Processor socket | BGA 1440 |
| Memory | |
| Internal memory type | DDR4-SDRAM |
| Internal memory | 16 GB |
| Memory form factor | SO-DIMM |
| Memory clock speed | 2666 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 32 GB |
| Memory layout (slots x size) | 2 x 8 GB |
| Graphics | |
| On-board graphics adapter | Y |
| On-board graphics adapter DirectX version | 12.0 |
| On-board graphics adapter model | Intel UHD Graphics P630 |
| On-board graphics adapter base frequency | 350 MHz |
| On-board graphics adapter dynamic frequency (max) | 1200 MHz |
| Maximum on-board graphics adapter memory | 64 GB |
| On-board graphics adapter OpenGL version | 4.5 |
| Storage | |
| Total storage capacity | 512 GB |
| Number of SSDs installed | 1 |
| Total SSDs capacity | 512 GB |
| Compatible memory cards | SD, SDHC, SDXC |
| Card reader integrated | Y |
| Storage media | SSD |
| Optical drive | |
| Optical drive type | N |
| Networking | |
| Ethernet LAN | N |
| Wi-Fi | Y |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Antenna type | 2x2 |
| Bluetooth | Y |
| Bluetooth version | 5.0 |
| 4G | N |
| 3G | N |
| Ports & interfaces | |
| Charging port type | DC-in jack |
| USB 3.0 (3.1 Gen 1) Type-A ports quantity | 2 |
| HDMI version | 2.0 |
| Combo headphone/mic port | Y |
| HDMI ports quantity | 1 |
| Thunderbolt 3 ports quantity | 2 |
| Audio | |
| Built-in microphone | Y |
| Number of built-in speakers | 2 |
| Audio system | Bang & Olufsen |
| Keyboard | |
| Numeric keypad | N |
| Island-style keyboard | Y |
| Full-size keyboard | Y |
| Keyboard backlit | Y |
| Pointing device | Clickpad |
| Performance | |
| Ambient light sensor | Y |
| Software | |
| Operating system installed | Windows 10 Pro for Workstations |
| Operating system architecture | 64-bit |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Number of battery cells | 4 |
| Battery capacity (Watt hours) | 95.6 Wh |
| Weight & dimensions | |
| Weight | 2 kg |
| Height (rear) | 1.74 cm |
| Height (front) | 8.8 mm |
| Depth | 254 mm |
| Width | 360 mm |
| Brand-specific features | |
| HP segment | Business |
| HP speaker type | HP Dual Speakers |
Disclaimer: Although we try to make the information as accurate as posible we do not guarantee it is 100% correct.
Download drivers: âĄī¸ HP ZBook Studio G5 4DB77AW Drivers Windows 10 - Autodetect drivers
