MSI Crosshair 16 - CROSSHAIR 16 MAX HX E2WGXK-044NL
MSI Crosshair 16
Product code: CROSSHAIR 16 MAX HX E2WGXK-044NL
- 💻Display diagonal: 16 inch
- 🔳Processor model: 290HX Plus
- 🎫Internal memory: 32 GB
- 🎮On-board graphics adapter model:
- 🎮Discrete graphics adapter model:
- 💽Total storage capacity: 1 TB
- ⚖️Weight: 2.2 kg
📊 Add to compare
Specifications
| Design | |
|---|---|
| Product colour | Black |
| Product type | Laptop |
| Form factor | Clamshell |
| Market positioning | Gaming |
| Housing material | Metal, Plastic |
| Original brand name | MSI |
| Display | |
| Display diagonal | 16 inch |
| Display brightness | 500 cd/m² |
| Panel type | IPS-Level |
| HD type | Quad HD+ |
| Touchscreen | No |
| Display resolution | 2560 x 1600 pixels |
| High Dynamic Range (HDR) technology | DisplayHDR True Black 1000 |
| RGB colour space | DCI-P3 |
| Colour gamut | 100% |
| High Dynamic Range (HDR) supported | Yes |
| Brand | MSI |
| Family | Crosshair |
| Model name | 16 |
| Part Number | CROSSHAIR 16 MAX HX E2WGXK-044NL |
| EAN/UPC code | 4711377461511 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core Ultra 9 |
| Processor boost frequency | 5.5 GHz |
| Processor model | 290HX Plus |
| Processor cores | 24 |
| Processor threads | 24 |
| Processor cache | 36 MB |
| Processor socket | BGA 2114 |
| Processor generation | Intel Core Ultra (Series 2) |
| Efficient-core base frequency | 1.8 GHz |
| Efficient cores | 16 |
| Performance cores | 8 |
| Performance-core Max Turbo Frequency | 5.5 GHz |
| Efficient-core Max Turbo Frequency | 4.7 GHz |
| Maximum turbo power | 160 W |
| Processor base power | 55 W |
| Performance-core base frequency | 2.7 GHz |
| Memory | |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 32 GB |
| Memory clock speed | 6400 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 128 GB |
| Memory layout (slots x size) | 2 x 16 GB |
| Graphics | |
| Discrete graphics memory type | GDDR7 |
| Discrete GPU manufacturer | NVIDIA |
| On-board graphics card | Yes |
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce RTX 5070 Laptop GPU |
| On-board graphics card model | Intel Graphics |
| On-board graphics card family | Intel Graphics |
| Discrete graphics card memory | 12 GB |
| On-board GPU manufacturer | Intel |
| Storage | |
| Total storage capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| Total SSDs capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| Compatible memory cards | SD |
| Card reader integrated | Yes |
| Storage media | SSD |
| NVMe | Yes |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 2500 Mbit/s |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.1 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Sleep-and-Charge | Yes |
| Thunderbolt 4 ports quantity | 1 |
| Intel® Thunderbolt 4 | Yes |
| USB Power Delivery (USB PD) | Yes |
| Audio | |
| Built-in microphone | Yes |
| Number of built-in speakers | 2 |
| Audio system | Nahimic 3 |
| Speaker power | 2 W |
| Camera | |
| Front camera | Yes |
| Privacy camera | Yes |
| Front camera HD type | HD |
| Privacy type | Privacy shutter |
| Video capturing speed | 30 fps |
| Front camera resolution | 1280 x 720 pixels |
| Keyboard | |
| Numeric keypad | Yes |
| Keyboard backlit colour | RGB |
| Keyboard layout | QWERTY |
| Keyboard backlit | Yes |
| Pointing device | Touchpad |
| Keyboard language | French |
| Keyboard backlit zone | 24-zone RGB |
| Copilot key | Yes |
| Software | |
| Operating system installed | Windows 11 Home |
| Bundled software | Discrete Graphics Mode, MSI AI Engine, MSI App Player, MSI Center, MSI Companion, Mystic Light, Nahimic 3, Nvidia App |
| Battery | |
| Battery weight | 283.8 g |
| Number of battery cells | 4 |
| Battery capacity | 5120 mAh |
| Weight & dimensions | |
| Weight | 2.2 kg |
| Height (rear) | 2.38 cm |
| Height (front) | 2.19 cm |
| Depth | 269.7 mm |
| Width | 363 mm |
| Power | |
| AC adapter power | 240 W |
| USB Type-C charging port | Yes |
| Security | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Neural processor unit (NPU) | |
| Neural processor unit (NPU) | Intel AI Boost |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to | 36 TOPs |
| NPU performance up to | 13 TOPs |
| GPU performance up to | 8 TOPs |
