MSI Katana 17 - KATANA 17 HX B14WFK-006FR
MSI Katana 17
Product code: KATANA 17 HX B14WFK-006FR
- 💻Display diagonal: 17.3 inch
- 🔳Processor model: i7-14650HX
- 🎫Internal memory: 32 GB
- 🎮On-board graphics adapter model:
- 🎮Discrete graphics adapter model:
- 💽Total storage capacity: 1 TB
- ⚖️Weight: 2.7 kg
📊 Add to compare
As an Amazon Associate I earn from qualifying purchases.
Specifications
| Design | |
|---|---|
| Product colour | Black |
| Product type | Laptop |
| Form factor | Clamshell |
| Market positioning | Gaming |
| Housing material | Plastic |
| Original brand name | MSI |
| Display | |
| Display diagonal | 17.3 inch |
| Maximum refresh rate | 240 Hz |
| Display brightness | 300 cd/m² |
| Panel type | IPS-Level |
| HD type | Quad HD |
| Touchscreen | No |
| Display resolution | 2560 x 1440 pixels |
| RGB colour space | DCI-P3 |
| Colour gamut | 100% |
| Brand | MSI |
| Family | Katana |
| Model name | 17 |
| Part Number | KATANA 17 HX B14WFK-006FR |
| EAN/UPC code | 4711377309608 |
|
|
|
| Processor | |
| Processor manufacturer | Intel |
| Processor family | Intel Core i7 |
| Motherboard chipset | Intel HM770 |
| Processor boost frequency | 5.2 GHz |
| Processor model | i7-14650HX |
| Processor cores | 16 |
| Processor threads | 24 |
| Processor cache | 30 MB |
| Processor generation | Intel Core i7 (14th gen) |
| Efficient-core base frequency | 1.6 GHz |
| Efficient cores | 8 |
| Performance cores | 8 |
| Performance-core Max Turbo Frequency | 5.2 GHz |
| Efficient-core Max Turbo Frequency | 3.7 GHz |
| Maximum turbo power | 157 W |
| Processor base power | 55 W |
| Performance-core base frequency | 2.2 GHz |
| Memory | |
| Internal memory type | DDR5-SDRAM |
| Internal memory | 32 GB |
| Memory clock speed | 5600 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 96 GB |
| Memory layout (slots x size) | 2 x 16 GB |
| Graphics | |
| Discrete graphics memory type | GDDR7 |
| Discrete GPU manufacturer | NVIDIA |
| On-board graphics card | Yes |
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA GeForce RTX 5060 |
| On-board graphics card model | Intel UHD Graphics |
| On-board graphics card family | Intel UHD Graphics |
| Discrete graphics card memory | 8 GB |
| On-board GPU manufacturer | Intel |
| Storage | |
| Total storage capacity | 1 TB |
| Number of SSDs installed | 1 |
| SSD capacity | 1 TB |
| Total SSDs capacity | 1 TB |
| SSD interface | PCI Express 4.0 |
| SSD form factor | M.2 |
| Storage media | SSD |
| NVMe | Yes |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Optical drive | |
| Optical drive type | No |
| Networking | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| WLAN controller model | Intel Wi-Fi 6E AX211 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| HDMI version | 2.1 |
| Combo headphone/mic port | Yes |
| DC-in jack | Yes |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| USB Sleep-and-Charge | Yes |
| USB Power Delivery (USB PD) | Yes |
| Audio | |
| Number of built-in speakers | 2 |
| Audio system | Nahimic 3 |
| Speaker power | 2 W |
| Camera | |
| Front camera | Yes |
| Front camera HD type | HD |
| Video capturing speed | 30 fps |
| Front camera resolution | 1280 x 720 pixels |
| Keyboard | |
| Numeric keypad | Yes |
| Keyboard backlit colour | RGB |
| Keyboard number of keys | 99 |
| Keyboard backlit | Yes |
| Pointing device | Touchpad |
| Keyboard backlit zone | 4-zone RGB |
| Copilot key | Yes |
| Software | |
| Operating system installed | Windows 11 Pro |
| Battery | |
| Number of battery cells | 4 |
| Battery capacity | 4850 mAh |
| Weight & dimensions | |
| Weight | 2.7 kg |
| Height | 27.8 mm |
| Depth | 275.6 mm |
| Width | 398 mm |
| Power | |
| AC adapter power | 240 W |
| AC adapter input voltage | 90 - 264 V |
| USB Type-C charging port | Yes |
| Security | |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
| Other features | |
| Anti-glare screen | Yes |
